LWL02 LoRaWAN IoT Water Leak Sensor

The LWL02 is a LoRaWAN Water Leak sensor that detects water leak events and sends its status it to a LoRaWAN network server. The LWL02 is small in size (40 x 15 x 15mm) and powered by 2 x standard AAA alkaline batteries that are easily replaced and can last for years (2-10) if good signal strength to the gateway. As well as detecting leaks, the LWL02 can be used to detect low water levels. This can be handy for fish tanks, water tanks and many other applications where water level is critical.
SKU: T2U-LWL02-AU915
Manufacturer: Dragino
*
$45.00 +GST
Availability: Out of stock
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

The LWL02 will periodically upload data records at a configurable interval (usually every 24 hours) to confirm its connection and status.  A data record is also sent as soon as a leak event is detected.  Each record contains the battery voltage, number of leak events with the duration of the most recent leak event. The LWL02 has a communication terminal accessible via a USB-TTL converter (purchased separately) for configuration and diagnostics. The LWL01 is easy to mount and comes with all necessary installation items.

Telemetry2U’s IoT Cloud servers offer a plug-and-play experience with a few types of leak detectors that work straight out of the box - with a simple installation that can be done by most users. Using Telemetry2U’s IoT platform, you can configure various types of alerts, including E-mail, SMS, or voice calls, ensuring that you are notified within seconds of a leak event. You’ll be able to take corrective action immediately and at the very least, save yourself a clean-up and potentially a lot of money.  You can read more about leak detection with Telemetry2U here.



Please note that all LoRaWAN end-devices sensor's supplied by Telemetry2U will work with 3rd party network/application servers, like TTN, but if you would like to use your sensors on Telemetry2U’s advanced, plug-and-play IoT Platform, then you will need to purchase a license by selecting from the drop-down box. Products purchased with a license will be shipped with the latest firmware and configuration optimised for T2U, with no programming or set-up required.



If you have any questions about how Telemetry2U can help you get your world on the IoT cloud, please get in touch with us today, we're here to help.

Attribute nameAttribute value
Features
  • LoRaWAN v1.0.3 Class A
  • SX1262 LoRa Core
  • Water leak detection
  • Runs of 2 x AAA Alkaline batteries
  • Band: AU915
  • AT commands to change parameters
  • Uplink periodically and on water leak events
  • Ability to change configuration remotely
Applications
  • Wireless alarm and security systems
  • Home and building automation
  • Industrial monitoring and control
  • Farming and agriculture
  • Aquariums
  • Laboratory monitoring
Package contents
  • 1 x LWL02 leak sensor
  • Mounting hardware
Dimensions and weight
  • Device size: 40 x 15 x 15mm
  • Device weight: 50g
  • Device size: 85 x 55 x 35m
  • Device weight: 100g
Documents

Download Directory
