Dragino LT-22222-L LoRaWAN I/O Controller
The Dragino LT-22222-L is a LoRaWAN-based I/O controller designed for long-range, low-power monitoring and control applications. It provides a practical way to connect digital inputs, digital outputs, relay outputs, and analogue signals to a LoRaWAN network, enabling reliable remote control and telemetry without complex wiring.
LoRaWAN Connectivity The LT-22222-L operates exclusively on LoRaWAN, making it well suited to private and managed LoRaWAN networks where long range, low power consumption, and predictable coverage are required. It supports secure uplink and downlink communication for both monitoring and control use cases.
Designed for Remote Control and Monitoring With multiple digital and analogue interfaces, the LT-22222-L can monitor input states, read analogue sensor values, and control external equipment via relay outputs. Common applications include irrigation and pump control, building automation, alarm monitoring, smart agriculture, and general industrial I/O control.
Enhanced Functionality with Telemetry2U Integration While the LT-22222-L can be connected to compatible third-party platforms, Telemetry2U is the recommended option for customers seeking a supported, end-to-end LoRaWAN solution. When integrated with the Telemetry2U IoT platform, the device can be configured with dashboards, historical data logging, alerts, and remote control capabilities, allowing users to move from raw I/O data to actionable outcomes.
Applications Enabled with Telemetry2U
Green House Condition Monitoring
Use LoRaWAN with Telemetry2U to monitor temperature, humidity, light, soil moisture, and automate greenhouse systems. Improve crop yields with scalable, cloud-based IoT control.... Read More
Millipore Water Quality Monitoring
Monitor key lab water quality parameters in real-time with Telemetry2U’s IoT integration for Merck Milli-Q systems. Receive instant alerts to ensure compliance and purity... Read More
Combine Your Device with the Telemetry2U IoT Platform
Combine your Dragino device with the Telemetry2U IoT platform to manage monitoring, control, alerts, and device configuration in one place. Telemetry2U enables clear dashboards, configurable notifications, and reliable device management to support real-world LoRaWAN deployments.
| Attribute name |
Attribute value |
|
Specifications
|
Specification
Product Name: Dragino LT-22222-L LoRaWAN I/O Controller
LoRa Technology: LoRaWAN® long range wireless communication, Class A & Class C support
Frequency Bands: CN470 / EU433 / EU868 / AS923 / AU915 / US915 / KR920 (region dependent firmware) :contentReference[oaicite:1]{index=1}
LoRaWAN Activation: OTAA / ABP
Microcontroller: STM32L072CZT6 :contentReference[oaicite:2]{index=2}
LoRa Chipset: SX1276 / SX1278 :contentReference[oaicite:3]{index=3}
Power
- Input Voltage: 7 – 24 V DC :contentReference[oaicite:4]{index=4}
- Idle Current: ~4 mA @ 12 V :contentReference[oaicite:5]{index=5}
- Transmit Current (20 dB): ~34 mA @ 12 V :contentReference[oaicite:6]{index=6}
Digital Interfaces
- 2 × Digital Inputs (bi-directional, max ~6 V) :contentReference[oaicite:7]{index=7}
- 2 × Digital Outputs (max ~36 V, 450 mA) :contentReference[oaicite:8]{index=8}
- Counting function supported via digital inputs :contentReference[oaicite:9]{index=9}
Relay Outputs
- 2 × Relay Outputs (5 A @ 250 VAC / 30 VDC) :contentReference[oaicite:10]{index=10}
Analog Inputs
- 2 × 0 – 20 mA Current Inputs (resolution ~0.01 mA) :contentReference[oaicite:11]{index=11}
- 2 × 0 – 30 V Voltage Inputs (resolution ~0.01 V) :contentReference[oaicite:12]{index=12}
Environmental & Physical
- Dimensions: ~135 × 70 × 30 mm :contentReference[oaicite:13]{index=13}
- Weight: ~105 g :contentReference[oaicite:14]{index=14}
LoRa Modulation & Features
- LoRa modulation with long range, high interference immunity :contentReference[oaicite:15]{index=15}
- AT command configuration support :contentReference[oaicite:16]{index=16}
Typical Applications
- Smart Buildings & Home Automation :contentReference[oaicite:17]{index=17}
- Logistics & Supply Chain Monitoring :contentReference[oaicite:18]{index=18}
- Smart Metering & Agriculture :contentReference[oaicite:19]{index=19}
- Smart Cities & Industrial Automation :contentReference[oaicite:20]{index=20}
|
|
