The TrackerD-LS, an open-source LoRaWAN Asset Tracker, revolutionizes asset management. Powered by an ESP32 MCU and Semtech’s LoRa technology, it captures precise location data through GPS and communicates seamlessly over LoRaWAN networks. Designed for professional use, this device is ideal for sophisticated tracking applications, enhancing operational efficiency across various industries.
Adaptive Motion Detection and Energy Efficiency: The TrackerD-LS stands out with its intelligent motion detection feature. When motion is sensed, the device increases data transmission frequency, ensuring timely and accurate tracking. Conversely, in the absence of movement, it conservatively saves power, prolonging battery life and ensuring long-term, maintenance-free operation.
Extended Coverage and Data Reliability: Utilizing the strengths of LoRa wireless technology, TrackerD-LS achieves exceptional range with minimal data-rate, perfect for expansive areas. This technology also ensures high interference immunity and low power consumption. Even in areas lacking LoRaWAN coverage, the TrackerD-LS reliably stores location data, transmitting it once network connectivity is re-established.
Long-Lasting and Developer-Friendly: Equipped with a robust 3000mAh Li-ion rechargeable battery, complemented by a solar panel, the TrackerD-LS promises years of uninterrupted service. Each device possesses unique OTAA keys for secure network joining. Additionally, its developer-friendly nature allows customization via the Arduino IDE, making it adaptable to a wide range of IoT solutions.
Choose the 12-Month Subscription with Telemetry2U
When you select a"12-month Platform Subscription", we take care of the initial setup for you. Your Dragino LoRaWAN with all be shipped with all necessary configurations for seamless integration into Telemetry2U's IoT platform. All you'll need to do is register your account with Telemetry2U and add and your device to your account - it's that easy.
Refer to our Quick Guide to help get started - you'll be up an running in no time!
| Attribute name |
Attribute value |
|
Features
|
Features:
- LoRaWAN 1.0.3 Class A
- ESP32 PICO D4
- SX1276/78 Wireless Chip
- Arduino IDE Compatible
- Open source hardware / software
- Regular/ Real-time GPS tracking
- Built-in3 axis accelerometer.
- Motion sensing capability
- Power Monitoring
- Charging circuit via USB port
- 3000mA Rechargeable Li-on Battery + Solar Panel
- Datalog
|
|
Applications
|
Applications:
- Logistics and Supply Chain Management
|
|
Specifications
|
Micro Controller:
- Espressif ESP32 PICO D4
- MCU: ESP32 PICO D4
- Integrated SPI flash : 4 MB
- RAM: 448 KB
- EEPROM: 520 KB
- Clock Speed: 32Mhz
Common DC Characteristics:
- Supply Voltage: 2.5v ~ 3.6v
- Operating Temperature: -40 ~ 60°C
LoRa Spec:
- Frequency Range, 168 dB maximum link budget.+20 dBm - 100 mW constant RF output vs.
- Band 1 (HF): 862 ~ 1020 Mhz
- +14 dBm high efficiency PA.
- Programmable bit rate up to 300 kbps.
- High sensitivity: down to -148 dBm.
- Bullet-proof front end: IIP3 = -12.5 dBm.
- Excellent blocking immunity.
- Low RX current of 10.3 mA, 200 nA register retention.
- Fully integrated synthesizer with a resolution of 61 Hz.
- FSK, GFSK, MSK, GMSK, LoRaTM and OOK modulation.
- Built-in bit synchronizer for clock recovery.
- Preamble detection.
- 127 dB Dynamic Range RSSI.
- Automatic RF Sense and CAD with ultra-fast AFC.
- Packet engine up to 256 bytes with CRC.
- LoRaWAN 1.0.3 Specification
Battery:
- 3000mA Li-on Battery power
- Built-in Solar Panel
Power Consumption:
- Sleeping Mode: 60uA
- LoRa Transmit Mode: 125mA @ 20dBm 44mA @ 14dBm
- Tracking: max: 38mA
|
|
