Versatile Tracking Solution for Diverse Needs
TrackerD stands at the forefront of tracking technology with its ESP32 MCU and Semtech LoRa Wireless Chip. Equipped with an array of sensors including GPS, WiFi, BLE, and environmental sensors, it caters to a broad spectrum of tracking scenarios from fleet vehicle management to equipment hire and shipping.
Developer-Friendly Design for Custom Applications: TrackerD is a haven for developers seeking to tailor tracking solutions. Its compatibility with Arduino IDE allows for extensive customisation, making it an ideal choice for innovative IoT solutions. This flexibility ensures that TrackerD can be adapted to meet the specific requirements of various tracking applications.
Long-Range Communication for Unmatched Tracking: The LoRa wireless technology in TrackerD enables data transmission over long distances at low data rates. This feature is crucial in tracking applications, ensuring consistent and reliable data communication even in extensive operational areas. Its ultra-long range spread spectrum communication, coupled with high interference immunity, ensures robust tracking performance.
Durable and Efficient: With a 1000mAh Li-on rechargeable battery, TrackerD is designed for prolonged use, making it a sustainable choice for long-term tracking needs. The unique OTAA keys for LoRaWAN network integration underscore its secure and efficient operational capability.
Enhanced Functionality with Telemetry2U Integration: Telemetry2U's platform enhances TrackerD's capabilities, offering real-time tracking data on maps, making it easier to monitor assets effectively. The platform facilitates the reception of timely alerts via email, SMS, and voice for events like button presses or unusual movements. Additionally, the ability to recover data automatically when the device is back in range ensures no data loss, while historical data is readily accessible in charts and tables for comprehensive analysis.
Choose the 12-Month Subscription with Telemetry2U
When you select a"12-month Platform Subscription", we take care of the initial setup for you. Your Dragino LoRaWAN with all be shipped with all necessary configurations for seamless integration into Telemetry2U's IoT platform. All you'll need to do is register your account with Telemetry2U and add and your device to your account - it's that easy.
Refer to our Quick Guide to help get started - you'll be up an running in no time!
| Attribute name |
Attribute value |
|
Features
|
Features:
- LoRaWAN 1.0.3 Class A
- ESP32 PICO D4
- SX1276/78 Wireless Chip
- Arduino IDE Compatible
- Open source hardware / software
- Regular/ Real-time GPS,BLE,WIFI tracking
- Built-in3 axis accelerometer (LIS3DH)
- Humidity / temperature sensor : GXCAS Technology GXHT3X
- Motion sensing capability
- Power Monitoring
- Charging circuit via USB port
- 1000mA Li-on Battery power
- Tri-color LED, Alarm button
- Datalog
|
|
Applications
|
Applications:
- Logistics and Supply Chain Management
- Human tracking
- Shipment tracking
- Fleet management
- Food safety and compliance
|
|
Specifications
|
Micro Controller:
- Espressif ESP32 PICO D4
- MCU: ESP32 PICO D4
- Bluetooth: Bluetooth V4.2 BR/EDR and Bluetooth LE
- WiFi : 802.11 b/g/n (802.11n up to 150 Mbps)
- Integrated SPI flash : 4 MB
- RAM: 448 KB
- EEPROM: 520 KB
- Clock Speed: 32Mhz
Common DC Characteristics:
- Supply Voltage: 5V via USB port or Internal li-on battery
- Operating Temperature: -40 ~ 60°C
LoRa Spec:
- Frequency Range, 168 dB maximum link budget.
- Band 1 (HF): 862 ~ 1020 Mhz
- +20 dBm - 100 mW constant RF output vs.
- +14 dBm high efficiency PA.
- Programmable bit rate up to 300 kbps.
- High sensitivity: down to -148 dBm.
- Bullet-proof front end: IIP3 = -12.5 dBm.
- Excellent blocking immunity.
- Low RX current of 10.3 mA, 200 nA register retention.
- Fully integrated synthesizer with a resolution of 61 Hz.
- FSK, GFSK, MSK, GMSK, LoRaTM and OOK modulation.
- Built-in bit synchronizer for clock recovery.
- Preamble detection.
- 127 dB Dynamic Range RSSI.
- Automatic RF Sense and CAD with ultra-fast AFC.
- Packet engine up to 256 bytes with CRC.
- LoRaWAN 1.0.3 Specification
Battery:
- 1000mA Li-on Battery power (for model TrackerD)
Power Consumption:
- Sleeping Mode: 200uA
- LoRa Transmit Mode: 125mA @ 20dBm 44mA @ 14dBm
- Tracking: max: 38mA
|
|
Package contents
|
Package Includes:
- TrackerD LoRaWAN GPS/BLE Tracker x 1
- USB recharge & program cable x 1
Dimensions and Weight:
- Device Size: 10 x 8.5 x 4 cm
- Weight: 111g
|
|
Documents
|
DataSheet, Document Base
User Manual -- Online Latest
Shared Folder for all Dragino Products |
