The Dragino LHT65N-PIR is a sophisticated sensor that brings a new level of efficiency to your IoT monitoring needs. Seamlessly integrated with Telemetry2U's platform, this sensor offers real-time temperature and humidity tracking, along with motion detection through its external PIR probe. Its compatibility with the LoRaWAN v1.0.3 Class A protocol ensures reliable and extended-range communication, making it ideal for a variety of professional applications, including smart irrigation, metering, and building automation.
With Telemetry2U, harness the power of immediate data visualisation on user-friendly dashboards, enabling quick and informed decision-making. The sensor's advanced technology ensures minimal power consumption, while its built-in 2400mAh battery promises longevity, operating efficiently for over five years* under optimal conditions.
Streamlined User Experience: The LHT65N-PIR is designed for ease of use, supporting wireless configuration and Over-The-Air (OTA) updates. This user-friendly approach, combined with the advanced features of the Telemetry2U platform, such as customisable email, SMS, and voice alerts, as well as detailed audit reports, elevates your IoT experience. Automate tasks and schedule activities effortlessly, ensuring your operations run smoothly and efficiently.
Choose the 12-Month Subscription with Telemetry2U
When you select a"12-month Platform Subscription", we take care of the initial setup for you. Your Dragino LoRaWAN with all be shipped with all necessary configurations for seamless integration into Telemetry2U's IoT platform. All you'll need to do is register your account with Telemetry2U and add and your device to your account - it's that easy.
Refer to our Quick Guide to help get started - you'll be up an running in no time!
| Attribute name |
Attribute value |
|
Features
|
Features:
- LoRaWAN v1.0.3 Class A protocol
- Frequency Bands: CN470/EU433/KR920/US915/EU868/AS923/AU915
- AT Commands to change parameters
- Remote configure parameters via LoRaWAN Downlink
- Support wireless OTA update firmware
- Firmware upgradeable via program port
- Built-in 2400mAh battery for up to 5 years of use.
- Built-in Temperature & Humidity sensor
- External PIR Sensor
- Tri-color LED to indicate working status
|
|
Applications
|
Applications:
- Wireless Alarm and Security Systems
- Home and Building Automation
- Automated Meter Reading
- Industrial Monitoring and Control
- Long range Irrigation Systems,etc.
|
|
Specifications
|
Built-in Temperature Sensor:
- Resolution: 0.01 °C
- Accuracy Tolerance : Typ ±0.3 °C
- Long Term Drift: < 0.02 °C/yr
- Operating Range: -40 ~ 85 °C
Built-in Humidity Sensor:
- Resolution: 0.04 %RH
- Accuracy Tolerance : Typ ±3 %RH
- Long Term Drift: < 0.02 °C/yr
- Operating Range: 0 ~ 96 %RH
External PIR Sensor:
- Base on RDB223 Sensor
- Cable Length : 1 meter
- Stable detect distance : 0~3 meter
|
|
Package contents
|
Package Includes:
- LHT65N-PIR Temperature/Humidity/PIR Motion Sensor x 1
Dimension and weight:
- Device Size: 13.5 x 7 x 3 cm
- Weight: 105g
- Package Size: 14.5 x 8 x 5 cm
- Weight: 170g
|
|
Documents
|
DataSheet, Document Base,Certificate
User Manual -- Online Latest
